LW39-25
Ideal for the places with greater capacity, especially suitable for the DC application environment. Rolling bearing is used inside for soft and gentle touch and long mechanical endurance.
-
Rated Insulation Voltage Ui:
690V
-
Rated Thermal Current Ith:
25A
-
Working Alternating Current
AC-15:220V/12A 380V/8A
AC-3:380V/12A
AC-4:380V/10A
AC-21:380V/25A
AC-22:380V/25A -
Working Direct Current
DC-13:110V/2.5A 220V/1.25A
Product Features
Technical Parameters
Main Parameters
|
Rated Insulation Voltage Ui: |
690V |
|
Rated Thermal Current Ith: |
25A |
|
Working Alternating Current |
AC-15:220V/12A 380V/8A、AC-3:380V/12A、AC-4:380V/10A、AC-21:380V/25A、AC-22:380V/25A |
|
Working Direct Current |
DC-13:110V/2.5A 220V/1.25A |
|
Power Frequency Withstand Voltage |
2500V, 1min |
|
AC Endurance |
200,000 times |
|
DC Endurance |
100,000 times |
|
Mechanical Endurance |
300,000 times |
|
Degree Of Protection For Head |
IP40 |
|
Altitude |
Not more than 2,000m |
|
Ambient Temperature |
-25℃～+55℃ |
|
Relative Humidity Of Air |
Not more than 90% |
|
Mounting Category |
Ⅲ |
|
Pollution Degree |
3 |
