LW39-10

Single-hole installation with installation hole diameter of ψ16mm or ψ22.5mm, globally popular built-in wiring,,limited mounting space, safe and reliable, IP65


Important Parameters
  • Rated Insulation Voltage Ui:

    440V

  • Rated Thermal Current Ith:

    10A

  • Working Alternating Current

    AC-15:110V/4A 220V/2A 380V/1.2A

  • Working Direct Current

    DC-13:110V/0.25A 220V/0.12A


Product Features

01

Single-hole mounting method is adopted.

02

The appearance is small, aesthetic and novel, with reliable structure.

03

Operating angle 30°, 45°, 90°.

04

Max. number of nodes in contact system is 8.

Technical Parameters

Main Parameters

Rated Insulation Voltage Ui:

440V

Rated Thermal Current Ith:

10A

Working Alternating Current

AC-15:110V/4A 220V/2A 380V/1.2A

Working Direct Current

DC-13:110V/0.25A 220V/0.12A

Power Frequency Withstand Voltage

2500V, 1min

AC Endurance

200,000 times

DC Endurance

100,000 times

Mechanical Endurance

300,000 times

Degree Of Protection For Head

IP65

Altitude

Not more than 2,000m

Ambient Temperature

-25℃~+55℃

Relative Humidity Of Air

Not more than 90%

Mounting Category

Pollution Degree

3
