ALH-0.66 SK**L

Novel design, advanced compensation method, excellent process technology, safe and reliable performance, small and aesthetic appearance, as well as complete varieties, ideal for control, protection, and measurement.


Important Parameters
  • Rated Insulation Voltage

    AC660V

  • Power Frequency Withstand Voltage

    3kV (1min, 50Hz; between the enclosure and secondary terminal)

  • Wide Range Of Hole Coverage

    6mm~46mm

  • Secondary Side Current

    2.5mA~60mA

  • Insulation Class

    B


Product Features

01

Wide range of hole coverage: 6mm~46mm

02

Secondary side current: 2.5mA~60mA

03

For small currents, ferrite materials are used: offering higher accuracy and are less prone to rusting.

04

Integrated TVS (Transient Voltage Suppression Diode): No open-circuit high voltage. Ensure safety.

05

Made of nylon material, with an insulation class of B

Technical Parameters

Main Parameters

Rated Operating Voltage (Un)

AC660V

Rated Frequency

50~60Hz

Power Frequency Withstand Voltage

3,000V (1min, 50Hz; between the enclosure and secondary terminal)

Insulation Class

B

Altitude

≤1,000m (for regular applications: for special applications at altitudes >1,000m, the appropriate transformers must be selected according to the constraints specified in GB20840)

Compliance Standards

GB20840

Primary Current

30A~720A

Secondary Current

2.5mA~5A

Ambient Temperature for Use

-25℃~+40℃

Maximum Temperature Resistance

120℃

Ambient Temperature for Storage

-40℃~+70℃

Accuracy Grade

0.5、1
